Design: Flat woven, double lay webbing (15 and 20 ton four lay) made in solid weaving. Colour coded. Folded eye both ends, with protection. Eye protection: Extra layer or grey polyester webbing. Length of protection shall cover min 40% of eye length L2 Eye length L2 (acc. to EN 1492-1 and AS 1353
Show more
Design: Flat woven, double lay webbing (15 and 20 ton four lay) made in solid weaving. Colour coded. Folded eye both ends, with protection. Eye protection: Extra layer or grey polyester webbing. Length of protection shall cover min 40% of eye length L2 Eye length L2 (acc. to EN 1492-1 and AS 1353.1). Up to 150 mm: Min. 3 x webbing width. Over 150 mm: Min. 2,5 x webbing width.
Chemical resistance: Resistant to most acids, but not strong alkalis.
Stretch with working load: 2-3%.
Length tolerance: Nominal length ±3%.
Material:
Polyester (PES), high tenacity multifilament.
Marking:
The slings are provided with a blue label and a white warning label.
Temperature range:
Approx. -40°C up to +100°C.
Safety factor:
8:1
Contact Us
Product FAQ
dimentions
A webbing sling is a flat textile lifting sling made from woven fibres. Its wide contact surface provides good load stability and helps distribute pressure, making it suitable for general lifting applications and for handling loads where a broader support area is beneficial..
The sling is manufactured with a safety factor of 8:1, meaning the minimum breaking strength is 8:1 times higher than the working load limit when used correctly and in accordance with applicable standards.
