At least 25% greater WLL than traditional Grade 8 products.
Proof Load tested at 2.5 times the WLL with certification for each batch manufactured.
Fatigue rated to 20,000 cycles at 1.5 times the WLL.
Tempering temperature minimum 400°C
- Material: Quenched and Tempered Alloy Steel.
- Marking: According to standard, Type, manufacturer ID, traceability.
- Temperature range: -40° up to +200°C (without reduction in WLL).
- Finish: Blue painted.
-
Standard:
EN 1677-1
Australian Standard: AS 3776
- Safety factor: 4:1
- Grade: 10
